OAK-FFC 4P

The OAK-FFC 4P integrates OAK-SoM-Pro and has 4 FFC interfaces which allow using up to 4 modular flexible flat cable (FFC) cameras (not included): two 2-lane MIPI and two 4-lane MIPI.

The design allows you to quickly prototype with various stereo baselines, fields of view, and image sensor permutations.

If you need to connect more cameras, check our OAK-FFC 6P variant.

Main Features:

• USB-C connector supporting USB2 and USB3 protocols (5Gbps / 10Gbps)
• 5V power input via barrel jack
• BMI270 IMU, 6-axis sensor combining accelerometer and gyroscope
• 4 TOPS of processing power

• Run any AI model, even custom architectured/built ones
• Encoding: H.264, H.265, MJPEG - 4K/30FPS, 1080P/60FPS
• Computer vision: warp/dewarp, resize, crop, edge detection, feature tracking
• Stereo depth perception with filtering, post-processing, RGB-depth alignment, and high configurability
• Object tracking: 2D and 3D tracking



Compatible cameras:

• OAK-FFC-IMX378: 12MP Color Rolling Shutter
• OAK-FFC-IMX378-FF: 12MP Color Rolling Shutter with Fixed Focus
• OAK-FFC-IMX378-W: 12MP Color Rolling Shutter with Wide Field of View
• OAK-FFC-OV9282: 1MP Grayscale Global Shutter
• OAK-FFC-OV9282-M12: 1MP Grayscale Global Shutter with M12 mount
• OAK-FFC-OV9282-W: 1MP Grayscale Global Shutter with Wide Field of View
• OAK-FFC-OV9782-M12: 1MP Color Global Shutter with M12 mount
• OAK-FFC-OV9782-W:  1MP Color Global Shutter with Wide Field of View
• OAK-FFC-IMX477-M12: 12MP Color Rolling Shutter with M12 mount
• OAK-FFC-IMX214-W: 13MP Color Rolling Shutter
• OAK-FFC-AR0234-M12: 2.3MP Color Global Shutter with M12 mount
• A variety of camera options from ArduCam



Documentation:

• Product Documentation
• Supported sensors



Package includes:

• OAK-FFC 4P board

• Flexible flat cable, 15cm (4pcs)
• Power supply with international adapters

• Cable USB-CA-1m


Camera modules are not included.

Part Number:

OAK-FFC-4P: A00470
